NCL I-60 UPVC Sliding Door

NCL i60 Sliding

The windows are fabricated from high quality UPVC profiles manufactured by ncl Veka limited, Hyderabad (a joint venture between NCL Group & Veka AG Germany). These windows have high resistance towards natural element, high durability and long life, smooth surface for easy maintenance, perfect heat and sound insulation and superior aesthetics. NCL i60 Sliding windows are recommended for club houses, premium hotels, premium group housing etc.

Features

No Leakages

Control Noise

Thermal Insulation

Maintenance Free

Fire retardant

Strong & durable

Save energy

Ec0-Friendly

Design & colors

Specifications

I - 60 Series (sliding) Specifications

providing and fixing sliding windows/doors, fabricated from unplasticised polyvinyl chloride (uPVC) sections with brand name wintech.

Profiles

The profiles should be hollow, three chamber system which provides high insulation properties with outer frame 60mm x 45mm with an outer wall thickness of 2.2mm. The window unit should be designed with all corner, joints mitred and fusion welded. Windows should be steel reinforced with 31x11mm & 23x20x5 mm steel reinforcement with a thickness of 1mm to have dimensional stability . The sash should be of 39 x 58mm. The profiles should have co-extruded seals.

Hardware

All the hardware like rollers, handles should be screwed with self tapping screws. The handles, locks should be designed so that they cannot be released from outside.

Glazing

The window system should glazed with 5mm plain float glass.

Installation

he profiles should be cut to length and welded 45 degrees. The window unit should be designed such that the water drainage does not pass through the reinforcement chamber. The window system should be fixed directly to the brick wall using self expanding nylon plug and driving ms electroplated screws into plug.
